Volvo VOE938227 Hose assembly aftermarket part for sale

Eternity/2 VOE938227 for Volvo excavator EC480EHR(S/N 390001-) excavator

Part Name: VOE938227 Hose assembly
KDSORT: 360, 110
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 4400
Hose Recipe Asmoverall Length Inch: 173.23
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 6
Hose Part Hose Size Inch: 1/4"
Hose Part Hose Dash: -04
Hose Part Hose Pressure Class MPA: 45.0
Hose Part Hose Pressure Class PSI: 6525
Hose Part Hose Pressure Class BAR: 450
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 14
Hose Part Hose Outer Diameter INCH: 0.55
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20719/916/1300, 20653/911/6400, 20228/911/6400

Looking for Part NO.VOE938227?
We supply Kubota / CASE / ISUZU / Deutz / Doosan / Hitachi spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.

VOE938227 for Volvo Working hydraulic, quick fit on boom(1045599 assembly)

Volvo VOE938227 Hose assembly suitable for 1045599 Working hydraulic, quick fit on boom assembly.

Volvo VOE938227(c.1045599) Hose assembly
Ref: 1045599 / 2 / 1
VOE8288987 / U Leak-off line for Quick fit equipment on boom
20228/911/6400

VOE938227 for Volvo Working hydraulic, quick fit on boom(1064865 assembly)

Volvo VOE938227 Hose assembly suitable for 1064865 Working hydraulic, quick fit on boom assembly.

Volvo VOE938227(c.1064865) Hose assembly
Ref: 1064865 / 2 / 1
VOE8293489 / U / DIGGING Boom
VOE8292314 / U / DIGGING Boom
20653/911/6400

VOE938227 for Volvo Working hydraulic, dipper arm cylinder on boom.(1085227 assembly)

Volvo VOE938227 Eternity/2 suitable for 1085227 Working hydraulic, dipper arm cylinder on boom. assembly.

Volvo VOE938227(c.1085227) Eternity/2
Ref: 1085227 / 27 / 1
VOE8297388 / U / W/HRV Boom Digging
20719/916/1300

hydraulic cylinder seal parts for sale offer Doosan / YANMAR / SUMITOMO / Kobelco / HYUNDAI / MITSUBISHI aftermarket parts. MOQ 1 pcs is available! VOLVO Part NO.VOE938227 is on sale now!

Part NO. VOE938227 for Volvo EC480EHR(S/N 390001-)
EXCAVATOR VOLVO EC480EHR
BASIC MACHINE
Product number 8297366, Serial number 390001-
CAB
Product number 8297057
Product number 8297058
ENGINE
Product number 15185568
Replacement version 17272079
Product number 15185569
Replacement version 17272080
Product number 17481129
Replacement version 17481323
Product no. 17479201
Replacement version 17510356
Product no. 17479200
Replacement version 17510359

Part NO. VOE938227 for Volvo EC460CHR(HIGH REACH DEMOLITION)
This catalogue lists spare parts for Excavator EC460CHR.
BASIC MACHINE
PROD NO. 8288953, EC460CHR, S/N 190001 - 190022
ENGINE
Part No. 8188757, D12D-P, S/N 110364 - , 8288626,
Emission-certified from EPA and EU

Part NO. VOE938227 for Volvo EC480DHR(HIGH REACH DEMOLITION S/N 290001-290024,291001-)
EXCAVATOR VOLVO EC480D HR
BASIC MACHINE
PROD NO. 8292269 S/N 290001-290024
CAB
PROD NO. 8292276
PROD NO. 8292275
ENGINE
D13H-D, EU
Product No. 15117871
Replacement version 15173113
D13H-C, US
Product No. 15049436
Replacement version 15173113
