China Made VOE14264532 Hydraulic hose parts for Volvo Excavator

Volvo EC450 ÅKERMAN(ÅKERMAN EC450 SER NO - 1781) excavator spare part VOE14264532 Hydraulic hose

Part Name: VOE14264532 Hydraulic hose
KDSORT: 210, 100, 160, 190, 140, 120, 230, 540
UE: U
ANT1: 1
GLB_ANM1: MARKED 32, CAB ELEVATION, MARKED 44, MARKED 43, MARKED 16, MARKED 24, CAB ELEVATION, Marked 25, Marked 26
Hose Recipe Asmoverall Length MM: 3600
Hose Recipe Asmoverall Length Inch: 141.73
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 36.5
Hose Part Hose Pressure Class PSI: 5293
Hose Part Hose Pressure Class BAR: 365
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 17
Hose Part Hose Outer Diameter INCH: 0.67
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 99529/914/100, 99522/914/800, 99522/916/200, 99515/440/300, 99514/914/200, 99528/914/200, 99515/914/100, 99521/914/800, 99522/914/900, 99529/440/200, 99521/914/900, 99521/916/200

Looking for Part NO.VOE14264532?
We supply HYUNDAI / MITSUBISHI / Kubota / Hitachi / KATO / Doosan spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.

VOE14264532 for Volvo Travel motor hydraulics, superstructure(FM192 assembly)

Volvo VOE14264532 Hydraulic hose suitable for FM192 Travel motor hydraulics, superstructure assembly.

Volvo VOE14264532(c.FM192) Hydraulic hose
Ref: FM192 / / 1
99515/440/300

VOE14264532 for Volvo Servo hydraulics, boom(FM184 assembly)

Volvo VOE14264532 Hydraulic hose suitable for FM184 Servo hydraulics, boom assembly.

Volvo VOE14264532(c.FM184) Hydraulic hose
Ref: FM184 / / 1
99515/914/100

VOE14264532 for Volvo Servohydraulik, travel(FU277B assembly)

Volvo VOE14264532 Hydraulic hose suitable for FU277B Servohydraulik, travel assembly.

Volvo VOE14264532(c.FU277B) Hydraulic hose
Ref: FU277B / 8,10 / 2
VOE14302024 / U Hydraulic control
99522/914/900

VOE14264532 for Volvo Servo hydraulics, Slewing(FT292B assembly)

Volvo VOE14264532 Eternity/2 suitable for FT292B Servo hydraulics, Slewing assembly.

Volvo VOE14264532(c.FT292B) Hydraulic hose
Ref: FT292B / 6 / 1
VOE14302024 / U Hydraulic control
99521/914/800

VOE14264532 for Volvo Travel motor hydraulics, superstructure(LC192A assembly)

Volvo VOE14264532 Eternity/2 suitable for LC192A Travel motor hydraulics, superstructure assembly.

Volvo VOE14264532(c.LC192A) Eternity/2
Ref: LC192A / / 1
99529/440/200

Excavator hydraulic cylinder seal parts supply CASE / MITSUBISHI / ISUZU / YANMAR / Hitachi / Komatsu spare parts. MOQ 1 pcs is available! Volvo Part NO.VOE14264532 is on sale now!

Part VOE14264532 suitable for:
VOE14302024 / U Hydraulic control
VOE14302320(VOE11702951) / U Hydr.quickfit equipment on boom, 6,7m
VOE14302319(VOE11703842) / U Hydr.quickfit equipment on boom, 6,0m
VOE14302319(VOE11703842) / U Hydr.quickfit equipment on boom, 6,0m
VOE14302321(VOE11702966) / U Hydr.quickfit equipment on boom, 7,0m
VOE14302024 / U Hydraulic control

Part NO. VOE14264532 for Volvo EC450 ÅKERMAN(ÅKERMAN EC450 SER NO - 1781)
EXCAVATOR EC450
BASIC MACHINE
PROD NO 14301003 EC450, SER NO 1601 - 1781
CAB
PROD NO 14244000
ENGINE
Part No. 499289 Type TD 122 KKE

Part NO. VOE14264532 for Volvo EC450(SER NO 1782-1909)
EXCAVATOR VOLVO EC450.
BASIC MACHINE
PROD NO 14301003 EC450 SER NO 1782 - 1909
CAB
PROD NO 14244000
ENGINE
Part No. 499289 Type TD 122 KKE.

Part NO. VOE14264532 for Volvo EC390(SER NO 1001-)
EXCAVATOR VOLVO EC390
BASIC MACHINE
PROD NO 14301001 EC390, CHWL. SER NO 1001 -
CAB
PROD NO 14267000
ENGINE
Part No. 497282 Type TD 103 KAE, ENG 277745 -

Part NO. VOE14264532 for Volvo EC340(SER NO 1001-)
EXCAVATOR VOLVO EC340
BASIC MACHINE
PROD NO 14301000 EC340, CLNL. SER NO 1001 -
PROD NO 14301002 EC340, CLWL. SER NO 1001 -
CAB
PROD NO 14267000
ENGINE
Part No. 497282 Type TD 103 KAE, ENG 277745 -

Part NO. VOE14264532 for Volvo EC650 ÅKERMAN(ÅKERMAN EC650 SER NO - 538)
EXCAVATOR EC650
BASIC MACHINE
PROD NO 14301037 EC650, SER NO 501 - 538
CAB
PROD NO 14244000
ENGINE
Part No. 499288 Typ TD 122 KIE

Part NO. VOE14264532 for Volvo EC650(SER NO 539-618)
EXCAVATOR VOLVO EC650
BASIC MACHINE
PROD NO 14301037 EC650 SER NO. 539 - 618
CAB
PROD NO 14244000
ENGINE
Part No. 499288 Typ TD 122 KIE
