Volvo excavator part VOE15152347 Hose assembly for sale

Volvo EC380E(S/N 310001-) VOE15152347 Rockmaster/1SC wholesale

Part Name: VOE15152347 Hose assembly
KDSORT: 520, 180, 110, 260, 570, 360, 220
UE: U
ANT1: 1
GLB_ANM1: S/N 110296-
Hose Recipe Asmoverall Length MM: 400
Hose Recipe Asmoverall Length Inch: 15.75
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 3 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 2
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 12
Hose Part Hose Size Inch: 1/2"
Hose Part Hose Dash: -08
Hose Part Hose Pressure Class MPA: 19.0
Hose Part Hose Pressure Class PSI: 2755
Hose Part Hose Pressure Class BAR: 190
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 20
Hose Part Hose Outer Diameter INCH: 0.79
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20740/916/720, 20715/914/475, 20718/914/610, 20641/916/260, 20138/916/1200, 20138/916/260, 20715/914/450, 20740/916/900, 20687/914/450, 20641/916/1200, 20687/914/460, 20718/914/620, 20718/914/600

Looking for Part NO.VOE15152347?
We supply CUMMINS / Deutz / SUMITOMO / Kobelco / SAMSUNG / Doosan aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.

VOE15152347 for Volvo Servo system, control valve piping.(1088205 assembly)

Volvo VOE15152347 Hose assembly suitable for 1088205 Servo system, control valve piping. assembly.

Volvo VOE15152347(c.1088205) Rockmaster/1SC
Ref: 1088205 / 2 / 1
VOE8293277 / P / EC380E Basic Machine
20687/914/460

VOE15152347 for Volvo Servo system, pump piping and filter mount.(1091137 assembly)

Volvo VOE15152347 Rockmaster/1SC suitable for 1091137 Servo system, pump piping and filter mount. assembly.

Volvo VOE15152347(c.1091137) Hose assembly
Ref: 1091137 / 27 / 1
VOE8296946 / P / EC380EHR Basic Machine
20718/914/610

VOE15152347 for Volvo Servo system, pump piping and filter mount.(1094951 assembly)

Volvo VOE15152347 Rockmaster/1SC suitable for 1094951 Servo system, pump piping and filter mount. assembly.

Volvo VOE15152347(c.1094951) Rockmaster/1SC
Ref: 1094951 / 27 / 1
VOE8296946 / P / EC380EHR Basic Machine
20718/914/620

VOE15152347 for Volvo Servo system, control valve piping., Servo system, control valve to remote control valve(1072126 assembly)

Volvo VOE15152347 Rockmaster/1SC suitable for 1072126 Servo system, control valve piping., Servo system, control valve to remote control valve assembly.

Volvo VOE15152347(c.1072126) Hose assembly
Ref: 1072126 / 2 / 1
VOE8293277 / P / EC380E Basic Machine
VOE8296122 / P / EC350E Basic Machine
20687/914/450, 20715/914/475, 20715/914/450

VOE15152347 for Volvo Working hydraulic, dipper arm cylinder on adjustable boom(1081165 assembly)

Volvo VOE15152347 Rockmaster/1SC suitable for 1081165 Working hydraulic, dipper arm cylinder on adjustable boom assembly.

Volvo VOE15152347(c.1081165) Rockmaster/1SC
Ref: 1081165 / 14 / 1
VOE8298205 / U Hose rupt. v. for dip arm, leak-off line on adj.boom
20740/916/720

We offer CUMMINS / MITSUBISHI / Kubota / ISUZU / Komatsu / Kobelco spare parts. MOQ 1 pcs is available! Volvo Part NO.VOE15152347 is on sale now!

Part VOE15152347 suitable for:
VOE8289291 / U Leak bracket for slope,rot.,quick fit,hose rupture
VOE8289124 / U Hose rupt. v. for dip arm, leak-off line on adj.boom
VOE8296320(VOE14701150) / U / 4,6M Hose rupture v. for dip arm, leak-off line on boom
VOE8296946 / P / EC380EHR Basic Machine
VOE8282308(VOE14574456) / U / 4,6M Hose rupture v. for dip arm, leak-off line on boom

Part NO. VOE15152347 for Volvo ECR145E(S/N 310001-)
EXCAVATOR VOLVO ECR145E
BASIC MACHINE
Product number 8296283, Serial number 310001-
CAB
Product number 8295958
Product number 8297796
Product number 8297797
Product number 8297798
Product number 8301655
Product number 8301656
Product number 8301657
Product number 8301658
ENGINE
Product number 17229198, D4 T4f
Product number 17229196, D4 T4f
Product number 17480990, D4 T4f
Product number 17506991, D4J T4f
Product number 17668804, D4 STAGE V

Part NO. VOE15152347 for Volvo EC350E(S/N 310001-)
EXCAVATOR VOLVO EC350E
BASIC MACHINE
Product number 8296122, Serial number 310001-
CAB
Product number 8293303
Product number 8293304
Product number 8295011
Product number 8295012
Product number 8302044
Product number 8302046
Product number 8302050
Product number 8302052
ENGINE
Product number 15185569
Replacement version 17272080
Product number 17481129
Replacement version 17481323
Product number 17479201
Replacement version 17510356

Part NO. VOE15152347 for Volvo EC380E(S/N 310001-)
EXCAVATOR VOLVO EC380E
BASIC MACHINE
Product no. 8293277, S/N 310001-
CAB
Product no. 8293303
Product no. 8293304
Product no. 8295011
Product no. 8295012
Product no. 8295391
Product no. 8302183
Product no. 8302044
Product no. 8302046
Product no. 8302050
Product no. 8302052
ENGINE
Product no. 15185568
Replacement version 17272079
Product no. 15185569
Replacement version 17272080
Product no. 17481129
Replacement version 17481323
Product no. 17479201
Replacement version 17510356
Product no. 17479200
Replacement version 17510359

Part NO. VOE15152347 for Volvo EC380EHR(S/N 390001-)
EXCAVATOR VOLVO EC380EHR
BASIC MACHINE
Product number 8296946, Serial number 390001-
CAB
Product number 8297057
Product number 8297058
ENGINE
Product number 15185568
Replacement version 17272079
Product number 15185569
Replacement version 17272080
Product number 17481129
Replacement version 17481323
Product no. 17479201
Replacement version 17510356
Product no. 17479200
Replacement version 17510359

Part NO. VOE15152347 for Volvo ECR145C(S/N 110001-)
This catalogue lists the spare parts for Excavator ECR145C.
BASIC MACHINE
PROD NO 8282208, ECR145C, SER NO ; 110001 -
ENGINE
Part No. : 14533106, D4E EAE3 Emission Certified from EPA/EU

Part NO. VOE15152347 for Volvo ECR145D(S/N 210001-210766)
EXCAVATOR VOLVO ECR145D
BASIC MACHINE
PROD NO. 8290284, S/N 210001- 210766
CAB
PART NO. 8290225, 8291326
ENGINE
PART NO. 15165683, D4, EU
part not stocked as spare part
PART NO. 17231751, replacement version
PART NO. 15083702, D4, US
part not stocked as spare part
PART NO. 17231719, replacement version

hydraulic cylinder seal parts for sale have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).

Original VOE15152347 included regular invoice.
Used/Second hand VOE15152347 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
