VOE936954 Hose assembly for Volvo Excavator spare

2024-04-10 22:04:22

View:

Volvo-VOE936954-wholesale

Volvo EW160D(S/N 220014-221107) Hose assembly Part NO. VOE936954

Part Name: VOE936954 Hose assembly
KDSORT: 130, 370, 200, 300, 260, 270, 440, 360, 120, 640, 560, 100, 460, 110
UE: U
ANT1: 1, 2, 3, 0002, 4
ANT2: 1, 0000, 4
ANT3: 1, 3
ANT4: 1, 0000
ANT5: 0000, 1
GLB_ANM1: S/N -120022, S/N 120023-, S/N 120102 -, S/N - 120101
Hose Recipe Asmoverall Length MM: 2700
Hose Recipe Asmoverall Length Inch: 106.30
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 2
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 22.5
Hose Part Hose Pressure Class PSI: 3263
Hose Part Hose Pressure Class BAR: 225
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 16
Hose Part Hose Outer Diameter INCH: 0.63
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20114/914/100, 20140/914/2100, 20742/914/100, 20628/914/400, 20744/914/190, 20628/914/110, 20628/914/170, 20627/914/400, 20625/914/3100, 20114/914/110, 20112/914/150, 20866/914/450, 20154/914/120, 20625/914/3150
Looking for Part NO.VOE936954?
We supply YANMAR / SAMSUNG / Kobelco / Deutz / MITSUBISHI / Komatsu spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
VOE936954 for Volvo Servo system, control valve to remote control valve(1027348 assembly)
Volvo VOE936954 Hose assembly suitable for 1027348 Servo system, control valve to remote control valve assembly.
Volvo VOE936954(c.1027348) Hose assembly
Ref: 1027348 / 24 / 1
VOE8282151 / U Float position for boom
20112/914/200
VOE936954 for Volvo Servo system, control valve to remote control valve(1061401 assembly)
Volvo VOE936954 Hose assembly suitable for 1061401 Servo system, control valve to remote control valve assembly.
Volvo VOE936954(c.1061401) Hose assembly
Ref: 1061401 / 9 / 3
VOE8287011 / U / PATTERN CHANGE, WITH FLOAT Control joystick
20154/914/110
VOE936954 for Volvo Servo system, control valve to remote control valve(1093667 assembly)
Volvo VOE936954 Rockmaster/1SC suitable for 1093667 Servo system, control valve to remote control valve assembly.
Volvo VOE936954(c.1093667) Rockmaster/1SC
Ref: 1093667 / 17 / 1
VOE8301057 / U / NO FLOAT POSITION Control joystick
20744/914/190, 20864/914/190
VOE936954 for Volvo Servo system, control valve to remote control valve(1050171 assembly)
Volvo VOE936954 Rockmaster/1SC suitable for 1050171 Servo system, control valve to remote control valve assembly.
Volvo VOE936954(c.1050171) Hose assembly
Ref: 1050171 / 6 / 2
VOE8299357 / U Servo control pattern change for lever control
20767/914/300
VOE936954 for Volvo Servo system, speed control(1089653 assembly)
Volvo VOE936954 Hose assembly suitable for 1089653 Servo system, speed control assembly.
Volvo VOE936954(c.1089653) Rockmaster/1SC
Ref: 1089653 / 11 / 4
VOE8291166 / U / FOR NON GERMANY MARKET 25KM/H Travel motor
VOE8290023 / U / FOR GERMANY MARKET 20 KM/H Travel motor
VOE8290934 / U / FOR NON GERMANY MARKET 20 KM/H Travel motor
VOE8291165 / U / FOR NON GERMANY MARKET 30 KM/H Travel motor
VOE8290932 / U / FOR GERMANY MARKET 20 KM/H Travel motor
VOE8290024 / U / FOR GERMANY MARKET 30 KM/H Travel motor
VOE8290933 / U / FOR NON GERMANY MARKET 20 KM/H Travel motor
VOE8291217 / U / FOR NON GERMANY MARKET 35 KM/H Travel motor
VOE8290935 / U / FOR NON GERMANY MARKET 30 KM/H Travel motor
20628/914/400, 20627/914/400
HydSeal.com supply HYUNDAI / CASE / Hitachi / CUMMINS / YANMAR / Deutz spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE936954 is on sale now!
Part VOE936954 suitable for:
VOE8294725 / U / FOR NON GERMAN MARKET Speed limiter max 20km/h
VOE8297087 / U / FOR GERMAN MARKET Speed limiter max 20km/h
VOE8286781 / U / NO PATTERN CHANGER Float position valve
VOE8289087 / U / NO PATTERN CHANGE Float position for boom
VOE8289085 / U / NO FLOAT NO PATTERN CHANGE Float position valve
VOE8280180 / U / WRIST PROPORTIONAL Control joystick
VOE8281168 / U / WRIST ON/OFF Control joystick
VOE8280915 / P / EW140C Excavator
VOE8289154 / U Servo control pattern change for lever control
VOE8289155 / U / WTHOUT PILOT PATTERN CHANGE Servo control pattern change for lever control
VOE8281168 / U / WRIST ON/OFF Control joystick
VOE8280180 / U / WRIST PROPORTIONAL Control joystick
VOE8282922 / U / NO PATTERN CHANGER Servo control pattern change for lever control
Part NO. VOE936954 for Volvo EWR170E(S/N 320011-)
EXCAVATOR VOLVO EWR170E
BASIC MACHINE
Product number 8301029, 8300994, Serial number 320011-
CAB
Product number 8295279
Product number 8292998
Product number 8294134
Product number 8295278
DRIVE AXLES
Part number 14693936, front
Part number 14693937, front
Part number 14590304, rear
Part number 14590306, rear
TRANSMISSION
Part number 14645850
ENGINE
Part number 17483700, D4J T4F
Part number 17483701, D4J T4F
Part number 17506995, D4J T4F
Part number 17668807, D4 STAGE V
Part NO. VOE936954 for Volvo EW230C(S/N 120010-120055)
EXCAVATOR VOLVO EW230C
BASIC MACHINE
PROD NO 8285381, EW230C
CAB
PART NO 11294016
PART NO 11294031
TRANSMISSION
PART NO 14385097
AXLE
PART NO 14386486, front, 2.75 M, 2.85 M
PART NO 14386485, rear, 2.75 M, 2.85 M
ENGINE
PART NO. 14387500, Type D6EEHE3
Part NO. VOE936954 for Volvo EW160C(S/N 120012-122219)
EXCAVATOR VOLVO EW160C
BASIC MACHINE
PROD NO 8280110, EW160C, S/N 120012 - 122219
CAB
PART NO 11294016
TRANSMISSION
PART NO 14385680
AXLE
PART NO 14385095, front
PART NO 14386745, front, 2.75 M
PART NO 14385096, rear
PART NO 14386746, rear, 2.75 M
PART NO 14590306, rear, 2.75 M
ENGINE
PART NO. 14385350, Type D6EEDE3
Part NO. VOE936954 for Volvo EC340D(S/N 210001-210482)
EXCAVATOR VOLVO EC340D
BASIC MACHINE
PROD NO. 8289415 , S/N 210001 - 210479
SUB BASIC MACHINE
PROD NO. 8290856, S/N 210016 - 210479
PROD NO. 8290857, S/N 210016 - 210479, Waste handler
CAB
PART NO. 11294089, 11294090
ENGINE
PART NO. 15117871, D13H-D STP4A, EU/US, 8289023
part not stocked as spare part
PART NO. 15049436, D13H-C STP4A, NA, 8289891
part not stocked as spare part
PART NO. 15173113, replacement version
Part NO. VOE936954 for Volvo EC380D(S/N 21/23/231/26 270001-, 280001-)
EXCAVATOR VOLVO EC380D
BASIC MACHINE
Product number 8289022, Serial number 210001-210684, 230001-230821, 231001-, 260001-260037, 270001-, 280001-
SUB BASIC MACHINE
Product number 8291893, Serial number 210112-
Product number 8291894, Serial number 230001-, 231001-, 260001-260037, 270001-, 280001-
Product number 8291539, Demolition, Serial number 210112-
Product number 8301352, Serial number 271596-, 280598-, 231138-
Product number 8301351, Serial number 271596-, 280598-, 231138-
CAB
PART NO. 11294089, 11294090
ENGINE
PART NO. 15117871, 13L, EU, 8289023
part not stocked as spare part
PART NO. 15049436, 13L, US, 8289891
part not stocked as spare part
PART NO. 15173113, replacement version
PART NO. 15049434, 13L, 8290569
part not stocked as spare part
PART NO. 17216261, replacement version
PART NO. 15049435, 13L, 8290568
part not stocked as spare part
PART NO. 17216264, replacement version
Part NO. VOE936954 for Volvo EC750D(S/N 280001-)
EXCAVATOR VOLVO EC750D
BASIC MACHINE
Product number 8296058, Serial number 280001-
CAB
Product number 8296059
Product number 8296063
Product number 8296143
Product number 8296144
Product number 8297938
Product number 8297939
Product number 8298006
Product number 8298064
Product number 8298065
Product number 8298066
Product number 8298413
Product number 8298414
Product number 8298417
Product number 8298418
ENGINE
Product number 15185601, D16 T3
Replacement version 17441775, D16 T3
We have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).
Original VOE936954 included regular invoice.
Used/Second hand VOE936954 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
