Volvo EC220E(S/N 310001-, 320001-) Hose assembly Part NO. VOE937258
Part Name: VOE937258 Hose assembly
KDSORT: 290, 280, 460, 420, 200, 320, 210, 190
UE: U
ANT1: 1
ANT2: 0000, 1
GLB_ANM1: S/N -310058/-320067, S/N -320040
Hose Recipe Asmoverall Length MM: 600
Hose Recipe Asmoverall Length Inch: 23.62
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 3 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Xtraflex/5000
Hose Part Hose Size DN: 19
Hose Part Hose Size Inch: 3/4"
Hose Part Hose Dash: -12
Hose Part Hose Pressure Class MPA: 35.0
Hose Part Hose Pressure Class PSI: 5075
Hose Part Hose Pressure Class BAR: 350
Hose Part Hose Standard ISO: ISO 18752-C
Hose Part Hose Standard SAE: Volvo 106
Hose Part Hose Standard EN: Volvo 106
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire spiralled four layer
Hose Part Hose Remark: Extreme flexibility
Hose Part Hose Outer Diameter MM: 32
Hose Part Hose Outer Diameter INCH: 1.26
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20888/911/300, 20731/911/1100, 20630/911/1600, 20725/911/700, 20732/911/1100, 20634/916/600, 20888/911/360, 20625/914/3100, 20726/911/420, 20255/911/1600, 20139/916/600, 20135/911/1600, 20097/911/1600, 20725/911/650
Looking for Part NO.VOE937258?
We supply CUMMINS / HYUNDAI / Kobelco / CASE / KATO / Deutz spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE937258 Hose assembly suitable for 1029377 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE937258(c.1029377) Hose assembly
Ref: 1029377 / 33 / 1
VOE8285347 / U Float position for boom
20255/911/1600
Volvo VOE937258 Xtraflex/5000 suitable for 1077935 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE937258(c.1077935) Xtraflex/5000
Ref: 1077935 / 11 / 1
VOE8294904 / U / WITH HRV Float position for boom
20725/911/700
Volvo VOE937258 Xtraflex/5000 suitable for 1049436 Working hydraulic, 2nd boom cylinder on adjustable boom assembly.
Volvo VOE937258(c.1049436) Xtraflex/5000
Ref: 1049436 / 37 / 1
VOE8292370 / U Hose rupt. v. for dip arm, leak-off line on adj.boom
VOE8288484 / U / WITHOUT Hose rupt. v. for dip arm, leak-off line on adj.boom
VOE8288483 / U Hose rupt. v. for dip arm, leak-off line on adj.boom
20634/916/600, 20139/916/600
Volvo VOE937258 Hose assembly suitable for 1078071 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE937258(c.1078071) Xtraflex/5000
Ref: 1078071 / 8 / 1
VOE8294492 / U / WITHOUT Float position for boom
20726/911/420
Volvo VOE937258 Hose assembly suitable for 1049981 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE937258(c.1049981) Xtraflex/5000
Ref: 1049981 / 10 / 1
VOE8297622 / U / W/O HRV Float position for boom
20731/911/1100, 20732/911/1100
Part VOE937258 suitable for:
VOE8302355 / U / W/O HRV, WITH HOLDING Float position for boom
VOE8301782 / U / WITH HRV Float position for boom
VOE8281242 / U / 2540MM UPPER FRAME Float position for boom
VOE8279850 / U Float position for boom
VOE8287327 / U / ELEVATED CAB Float position for boom
VOE8294905 / U / W/O HRV Float position for boom
VOE8289389 / U 2 Pcs Boom Without X1
Part NO. VOE937258 for Volvo EC235C(S/N 120001-120106)
This catalogue lists the spare parts for Excavator EC235C.
BASIC MACHINE
PROD NO 8279769, EC235C, KONZ SER NO ; 120001 - 120106
ENGINE
Part No. 14549720, D6E EGE3. Emission-certified from EPA and EU
Part NO. VOE937258 for Volvo EC235D(S/N 220001-220035)
EXCAVATOR VOLVO EC235D
BASIC MACHINE
PROD NO. 8289742, S/N 220001- 220035
CAB
PART NO. 11294093, 11294094
ENGINE
PART NO. 15165690, D6H , EU
part not stocked as spare part
PART NO. 17231343, replacement version
Part NO. VOE937258 for Volvo EC220D(S/N 21/22/23/231/24/245 /26/27/28)
EXCAVATOR VOLVO EC220D
BASIC MACHINE
PROD NO. 8289742, S/N 210001-210889, 220001-221458, 230001-230418, 231001-, 240001-, 245001-, 260001-260111, 270001-, 280001-
SUB BASIC MACHINE
PROD NO. 8292707, S/N 210001-210889, 220001-221458
PROD NO. 8292038, S/N 230001-230418, 231001-, 240001-, 245001-, 260001-260111, 270001-, 280001-
PROD NO. 8292708, WASTEHANDLER
PROD NO. 8292709, DEMOLITION
PROD NO. 8301345, S/N 270789-, 280692-, 231204-
PROD NO. 8301346, S/N 270789-, 280692-, 231204-
CAB
PROD NO. 8290413
PROD NO. 8290414
PROD NO. 8290415
PROD NO. 8290416
PROD NO. 8291311
PROD NO. 8293085
PROD NO. 8293086
PROD NO. 8293087
PROD NO. 8293088
PROD NO. 8293089
PROD NO. 8293090
PROD NO. 8293091
PROD NO. 8293092
PROD NO. 8299644
PROD NO. 8301691
ENGINE
PART NO. 15165690, D6H part not stocked as spare part
PART NO. 17231272 replacement version
PART NO. 15083723, D6H part not stocked as spare part
PART NO. 17231270 replacement version
PART NO. 17216591, D6 part not stocked as spare part
PART NO. 14536076 replacement version
PART NO. 14536073, D6
Part NO. VOE937258 for Volvo ECR305C(S/N 110001-)
This catalogue lists the spare parts for Excavator ECR305C.
BASIC MACHINE
PROD NO 8285324, ECR305C, SER NR ; 110001 -
ENGINE
Part no. : 14575315, D7E EAE3 Emission-Certified from EPA/EU
Part NO. VOE937258 for Volvo FC2421C(S/N 110001-110078)
This catalogue lists the spare parts for Excavator FC2421C.
BASIC MACHINE
PROD NO 8284052, FC2421C, S/N 110001-110078
ENGINE
Part No. 14527730, D6E EAE3. Emission Certified from EPA and EU
Part NO. VOE937258 for Volvo EC200E(S/N 310011-)
EXCAVATOR VOLVO EC200E
BASIC MACHINE
Product number 8301794, Serial number 310011-
CAB
Product number 8292998
Product number 8294134
Product number 8295278
Product number 8295279
Product number 8300787
Product number 8300788
Product number 8300789
Product number 8300790
ENGINE
Product number 16064173, D4 T4F US
Product number 16064174, D4 T4F EU
