Volvo VOE938405 Hose assembly wholesale
Part Name: VOE938405 Hose assembly
KDSORT: 160, 120, 360, 440, 240
UE: U
ANT1: 1
ANT2: 1
ANT3: 1
GLB_ANM1: S/N 115011-115040
Hose Recipe Asmoverall Length MM: 3100
Hose Recipe Asmoverall Length Inch: 122.05
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 2
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 12
Hose Part Hose Size Inch: 1/2"
Hose Part Hose Dash: -08
Hose Part Hose Pressure Class MPA: 35.0
Hose Part Hose Pressure Class PSI: 5075
Hose Part Hose Pressure Class BAR: 350
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 21
Hose Part Hose Outer Diameter INCH: 0.83
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20434/914/3600, 20102/924/1000, 20101/924/1050, 20213/924/1050, 20100/924/1050, 20214/924/1050, 20101/924/1010, 20102/924/1050, 20100/924/1000
Looking for Part NO.VOE938405?
We offer CASE / Komatsu / HYUNDAI / Kubota / Hitachi / SUMITOMO aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE938405 Eternity/2 suitable for 1025709 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE938405(c.1025709) Hose assembly
Ref: 1025709 / 3 / 1
VOE8285672 / U / WITHOUT Leak-off line for slope-rotator on basic machine
20101/924/1050, 20100/924/1050
Volvo VOE938405 Hose assembly suitable for 1025582 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE938405(c.1025582) Eternity/2
Ref: 1025582 / 7 / 1
VOE8286208 / P / PL4611 Basic Machine
VOE8287463 / P / PL4608 Basic Machine
VOE8280287 / U / WITHOUT Leak-off line for slope-rotator on basic machine
20213/924/1050, 20214/924/1050, 20102/924/1050
Volvo VOE938405 Hose assembly suitable for 1025581 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE938405(c.1025581) Hose assembly
Ref: 1025581 / 24 / 1
VOE8280288(VOE14564602) / U / ON/OFF CONTROL Leak-off line for slope-rotator on basic machine
VOE8280090(VOE14564604) / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
20102/924/1000
Volvo VOE938405 Hose assembly suitable for 1025708 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE938405(c.1025708) Hose assembly
Ref: 1025708 / 31 / 1
VOE8285674(VOE14592467) / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
VOE8285673(VOE14592466) / U / ON/OFF Leak-off line for slope-rotator on basic machine
20100/924/1000, 20101/924/1010
Volvo VOE938405 Eternity/2 suitable for 1039698 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE938405(c.1039698) Hose assembly
Ref: 1039698 / 15 / 3
VOE8286692(VOE14602762) / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
VOE8286690 / U / WITHOUT Leak-off line for slope-rotator on basic machine
VOE8286691(VOE14602761) / U / ON/OFF Leak-off line for slope-rotator on basic machine
20434/914/3600
We offer Kobelco / Komatsu / Doosan / MITSUBISHI / CASE / SAMSUNG spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE938405 is on sale now!
Part NO. VOE938405 for Volvo EC460C(S/N 115001-115434)
This catalogue lists spare parts for Excavator EC460C.
BASIC MACHINE
PROD NO. 8280026, EC460C, S/N 115001 - 115434
ENGINE
Part No. 8188757, D12D-P, 8286626,
Emission-certified from EPA and EU
Part NO. VOE938405 for Volvo EC460C
This catalogue lists the spare parts for Excavator EC460C.
BASIC MACHINE
PROD NO. 8280026, EC460C, SER NO ; 110001 -
ENGINE
Part No. 8188764, D12D : Emission-certified from EPA and EU
Part NO. VOE938405 for Volvo PL4611
This catalogue lists the spare parts for Pipe Layer PL4611.
BASIC MACHINE
PROD NO. 8286208, PL4611, S/N 110001 - 110071
ENGINE
Part No. 8188764, D12D EAE3, S/N - 110268, 8279675
Emission-certified from EPA and EU
Part No. 8188756, D12D-H, S/N 110269 - 110363, 8279675
Part No. 8188757, D12D-P, S/N 110364 - , 8279675
Part NO. VOE938405 for Volvo EC330C(S/N 110001 - 110158, 140001 - 140055)
This catalog lists the spare parts for Excavator EC330C
BASIC MACHINE
PROD NO. 8281065, EC330C, S/N 110001 - 110158 KOR
PROD NO. 8281065, EC330C, S/N 140001 - 140055 USA
ENGINE
Part No. 8188768, D12DEBE3, 8280231
S/N - 110052 KOR;
Emission-certified from EPA and EU
Part No. 8188756, D12D-H, 8280231
S/N 110053 - 110064 KOR,
S/N 140001 - 140005 USA
Part No. 8188757, D12D-P, 8280231
S/N 110065 - KOR,
S/N 140006 - USA
Part NO. VOE938405 for Volvo PL4608(S/N 110001 - 110086)
This catalogue lists the spare parts for Pipe Layer PL4608.
BASIC MACHINE
PROD NO. 8287463, PL4608, SER NO. 110001 - 110086
ENGINE
Part No. 8188764, D12D EAE3, S/N - 110268, 8279675
Emission-certified from EPA and EU
Part No. 8188756, D12D-H, S/N 110269 - 110363, 8279675
Part No. 8188757, D12D-P, S/N 110364 - , 8279675
Part NO. VOE938405 for Volvo EC360C
This catalogue lists the spare parts for Excavator EC360C
BASIC MACHINE
PROD NO 8280830, EC360C, S/N 110001 - 115000 KOR
PROD NO 8280830, EC360C, S/N 140001 - 145000 USA
ENGINE
Part No. 8188768, D12DEBE3, S/N - 110411 KOR;
Emission-certified from EPA and EU
Part No. 8188756, D12D-H, S/N 110412 - 110481 KOR, 8280231
Part No. 8188756, D12D-H, S/N 140012 - 140044 USA, 8280231
Part No. 8188757, D12D-P, S/N 110482 - KOR, 8280231
Part No. 8188757, D12D-P, S/N 140045 - USA, 8280231
