Volvo SA9451-03213 Rockmaster/1SC aftermarket part for sale

2024-04-10 22:28:28

View:

VOLVO-SA9451-03213-in-stock

Volvo EC460B(S/N 10001-11514) excavator spare part SA9451-03213 Hose assembly

Part Name: SA9451-03213 Hose assembly
KDSORT: 250
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 650
Hose Recipe Asmoverall Length Inch: 25.59
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 22.5
Hose Part Hose Pressure Class PSI: 3263
Hose Part Hose Pressure Class BAR: 225
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 16
Hose Part Hose Outer Diameter INCH: 0.63
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 56136/911/700
Looking for Part NO.SA9451-03213?
We offer SAMSUNG / Komatsu / Kobelco / HYUNDAI / ISUZU / Kubota aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
SA9451-03213 for Volvo Hydraulic system, oil cooling system(SV210 assembly)
Volvo SA9451-03213 Hose assembly suitable for SV210 Hydraulic system, oil cooling system assembly.
Volvo SA9451-03213(c.SV210) Rockmaster/1SC
Ref: SV210 / 13 / 1
VOE8277120 / P / EC460B Basic Machine
56136/911/700
We supply Kubota / CUMMINS / Deutz / SAMSUNG / CASE / Hitachi spare parts. MOQ 1 pcs is available! Volvo Part NO.SA9451-03213 is on sale now!
Part NO. SA9451-03213 for Volvo EC460B(S/N 10001-11514)
This catalog lists the spare parts for Excavator EC460B.
BASIC MACHINE
PROD NO 8277120, EC460B, SER NO : 10001 - 11514
ENGINE
Part No. 8188167, D12C EAE2, S/N 10001 - 10311, 8277120
Part No. 8188167, D12C EAE2, S/N 10312 - , 8278900
Part No. 8188175, D12C EBE2, S/N 10312 - , 8278901
Part No. 8188179, D12C EFE2, S/N 10312 - , 8278902
We have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).
Original SA9451-03213 included regular invoice.
Used/Second hand SA9451-03213 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
