Volvo Hose assembly Part NO. VOE16229915
Part Name: VOE16229915 Hose assembly
KDSORT: 230, 110, 300
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 1350
Hose Recipe Asmoverall Length Inch: 53.15
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 8
Hose Part Hose Size Inch: 5/16"
Hose Part Hose Dash: -05
Hose Part Hose Pressure Class MPA: 40.0
Hose Part Hose Pressure Class PSI: 5800
Hose Part Hose Pressure Class BAR: 400
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 15
Hose Part Hose Outer Diameter INCH: 0.59
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20755/924/500, 20698/924/525, 20698/924/500, 20756/924/550, 20756/924/525, 20698/924/575, 20698/924/550, 20754/924/550, 20756/924/575, 20756/924/500, 20755/924/575, 20754/924/525, 20755/924/525, 20754/924/500
KDSORT: 230, 110, 300
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 1350
Hose Recipe Asmoverall Length Inch: 53.15
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 8
Hose Part Hose Size Inch: 5/16"
Hose Part Hose Dash: -05
Hose Part Hose Pressure Class MPA: 40.0
Hose Part Hose Pressure Class PSI: 5800
Hose Part Hose Pressure Class BAR: 400
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 15
Hose Part Hose Outer Diameter INCH: 0.59
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20755/924/500, 20698/924/525, 20698/924/500, 20756/924/550, 20756/924/525, 20698/924/575, 20698/924/550, 20754/924/550, 20756/924/575, 20756/924/500, 20755/924/575, 20754/924/525, 20755/924/525, 20754/924/500
Looking for Part NO.VOE16229915?
We supply Doosan / Deutz / Hitachi / HYUNDAI / SUMITOMO / Komatsu spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
We supply Doosan / Deutz / Hitachi / HYUNDAI / SUMITOMO / Komatsu spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE16229915 Eternity/2 suitable for 1077755 Hyd. circuit (quickfit/double-acting) assembly.
Volvo VOE16229915(c.1077755) Eternity/2
Ref: 1077755 / 11 / 1
VOE11871703 / U / QUICK ATTACH DE LONG ARM Quick attachment hydr.
VOE11871704 / U / QUICK ATTACH DE LONG ARMM Quick attachment hydr.
VOE11871415 / U Quick attachment hydr.
VOE11871702 / U / QUICK ATTACH DE SHORT ARM Quick attachment hydr.
VOE11871705 / U / QUICK ATTACH DE LONG ARMM Quick attachment hydr.
VOE11871416 / U Quick attachment hydr.
20755/924/550, 20754/924/575, 20698/924/550, 20754/924/550, 20755/924/575, 20698/924/575, 20756/924/550, 20756/924/575
Ref: 1077755 / 11 / 1
VOE11871703 / U / QUICK ATTACH DE LONG ARM Quick attachment hydr.
VOE11871704 / U / QUICK ATTACH DE LONG ARMM Quick attachment hydr.
VOE11871415 / U Quick attachment hydr.
VOE11871702 / U / QUICK ATTACH DE SHORT ARM Quick attachment hydr.
VOE11871705 / U / QUICK ATTACH DE LONG ARMM Quick attachment hydr.
VOE11871416 / U Quick attachment hydr.
20755/924/550, 20754/924/575, 20698/924/550, 20754/924/550, 20755/924/575, 20698/924/575, 20756/924/550, 20756/924/575
Volvo VOE16229915 Hose assembly suitable for 1077752 Hydraulic circuit (quick-coupling attachment / single-acting) assembly.
Volvo VOE16229915(c.1077752) Eternity/2
Ref: 1077752 / 2 / 1
VOE11871699 / U / QUICK ATTACH SE LONG ARM Quick attachment
VOE11871413 / U Quick attachment
VOE11871414 / U Quick attachment
VOE11871700 / U / QUICK ATTACH SE SHORT ARM Quick attachment
VOE11871701 / U / QUICK ATTACH SE LONG ARMM Quick attachment
VOE11871698 / U / QUICK ATTACH SE SHORT ARM Quick attachment
20754/924/525, 20698/924/500, 20698/924/525, 20755/924/500, 20755/924/525, 20756/924/500, 20756/924/525, 20754/924/500
Ref: 1077752 / 2 / 1
VOE11871699 / U / QUICK ATTACH SE LONG ARM Quick attachment
VOE11871413 / U Quick attachment
VOE11871414 / U Quick attachment
VOE11871700 / U / QUICK ATTACH SE SHORT ARM Quick attachment
VOE11871701 / U / QUICK ATTACH SE LONG ARMM Quick attachment
VOE11871698 / U / QUICK ATTACH SE SHORT ARM Quick attachment
20754/924/525, 20698/924/500, 20698/924/525, 20755/924/500, 20755/924/525, 20756/924/500, 20756/924/525, 20754/924/500
We offer Doosan / Hitachi / Deutz / YANMAR / SAMSUNG / Komatsu spare parts. MOQ 1 pcs is available! Volvo Part NO.VOE16229915 is on sale now!
Part NO. VOE16229915 for Volvo ECR40D
EXCAVATOR VOLVO ECR40D
BASIC MACHINE
Product number 11839928, Serial number 14004-
Product number 11839932, Serial number 24002-
CAB
Product number 15680948
ENGINE
Product number 15685538
Product number 15691466
EXCAVATOR VOLVO ECR40D
BASIC MACHINE
Product number 11839928, Serial number 14004-
Product number 11839932, Serial number 24002-
CAB
Product number 15680948
ENGINE
Product number 15685538
Product number 15691466
Part NO. VOE16229915 for Volvo EC35D
EXCAVATOR VOLVO EC35D
BASIC MACHINE
Product number 11839929, Serial number 13007-
Product number 11839933, Serial number 23002-
CAB
Product number 15680948
ENGINE
Product number 15685538
Product number 15691466
EXCAVATOR VOLVO EC35D
BASIC MACHINE
Product number 11839929, Serial number 13007-
Product number 11839933, Serial number 23002-
CAB
Product number 15680948
ENGINE
Product number 15685538
Product number 15691466
Part NO. VOE16229915 for Volvo ECR35D
EXCAVATOR VOLVO EC35D
BASIC MACHINE
Product number 11839920, Serial number 33505-
Product number 11839931, Serial number 43501-
CAB
Product number 15680948
ENGINE
Product number 15685538
Product number 15691466
EXCAVATOR VOLVO EC35D
BASIC MACHINE
Product number 11839920, Serial number 33505-
Product number 11839931, Serial number 43501-
CAB
Product number 15680948
ENGINE
Product number 15685538
Product number 15691466
Part NO. VOE16229915 for Volvo ECR50D
EXCAVATOR VOLVO ECR50D
BASIC MACHINE
PROD NO. 11839921 S/N 5038-
PROD NO. 11839922 S/N 16500-
ENGINE
Part No. 15661028
EXCAVATOR VOLVO ECR50D
BASIC MACHINE
PROD NO. 11839921 S/N 5038-
PROD NO. 11839922 S/N 16500-
ENGINE
Part No. 15661028
